Model Type:ControlLogix
Processor Model Number:1756-L1M1
Manufacturer:Allen-Bradley
Memory:16 MB
I/O Memory:0.98 MB
Isolation:30 V (Continuous)
Basic Insulation Type:Type
USB Port:To Backplane
Enclosure:Open Type
RFI Suppression:Radiated: 10 V/M With 1 KHZ Sine-Wave 80% AM From 80 – 2000 MHZ, 10 V/M With 200 Hz 50% Pulse 100% AM At 900 MHz, 10 V/M With 200 Hz 50%
Configuration:Backward-compatible with previous MVI56-MNETR versions
Ethernet Compatibility:Single-Slot ControlLogix backplane compatible, 10/100 Mbps auto crossover detection, Ethernet configuration and application port
User Memory:Up to 5000, 16-bit registers
CIPconnect Support:Enabled network configuration and diagnostics monitoring
Remote Image Size:Optimized for remote rack implementations
Software Tools:ProSoft Configuration Builder (PCB) software
Weight:0.32 kg
The AB 1756-L1M1 ControlLogix Logix5550 Processor is engineered for seamless integration into existing industrial systems, offering unparalleled flexibility and scalability. Its advanced features include a robust memory system that supports extensive user-defined applications, ensuring optimal performance under diverse operational conditions.
Equipped with an open type enclosure, this processor ensures reliable operation even in harsh environments. The integrated RFI suppression technology safeguards against electromagnetic interference, guaranteeing uninterrupted operation and high data integrity.
With backward compatibility and support for 10/100 Mbps Ethernet, the processor ensures compatibility with a wide range of devices and systems, facilitating easy setup and integration. The inclusion of a USB port for connection to the backplane further enhances its connectivity capabilities.
Designed with efficiency in mind, the AB 1756-L1M1 boasts an optimized remote image size, making it ideal for deployment in remote rack configurations. This feature, coupled with its user-friendly interface and extensive documentation, ensures quick setup and maintenance.
To facilitate seamless integration and configuration, the ProSoft Configuration Builder (PCB) software is provided, allowing users to define and map their module data memory efficiently. This software tool streamlines the setup process, saving time and effort during installation and maintenance.
